Aura Smart

This printer is a perfect solution for printing on T-shirts / Panels with Pigment inks. It works on white, light, as well as dark base.
Normally for printing on white & light-colored T-shirts the printing is done only using CMYK colors; whereas on black or dark t-shirts a white base is printed first and then on top of it there is CMYK printing.

“SMART” uses a special software and sensor technology which makes the registration easy and can print multiple copies without ripping the designs again and again. It is ready for NEOSTAMPA, which is the best RIP software available from Spain.

Main Features:

  • Print on Light / Dark Garments
  • Production: 80 to 100 T-shirts/hour
  • Fine Printing | Brilliant Colours
  • EPSON Gold generation printheads.
  • White / Glitter, etc done by Screen Printing. (Digital white optional).
  • Standard Printing width 145 cm. (Sweater Printer 160/180 cm option).
  • Post-treatment: Heat fixing through tunnel heater/heat curing box.
  • Special models available for Sweaters, Shawls and Shoes

Applications

Specifications

MODELS AURA SMART 4H AURA SMART 4W
No of Heads 4
Head Type LW007
Ink Droplet Size Variable Drop 3 to 21 pl
Productivity A4 Size Full Print 82-120 T-Shirts
Working Size 145 cm x 6 Mtr
Flash Heater Optional (Recommended)
Feed & Take Up Multiple of 3 Mtr Add on
Media T-shirts / Fabrics / Garments / Denim / Jute etc.
Features Combination of screen & digital. Printing full tables or pallets. Sensor-based registration. Adjustable head height. Suitable for high production
Ink Pigment
No of Colors 4/8 4+1
Supply Mode Continuous Ink Supply System
Operating System Windows 10 64 Bit
RIP Software Neostampa (Recommended)
Data Interface Hi-USB 2.0/3.0 Mbps
Power A/C 220 V 50/60 Hz
Environment Temperature: 15 to 250C Humidity: 55 to 65
Dimension (Machine) 2750x6000x1200 mm (6 mtr.)
Weight (Machine) 380 Kg
Dimension (Packing) 3150x500x630 mm 2860x630x720 mm
Weight (Packing) 280 Kg 220 Kg

Inks

InksPackingCyanMagentaYellowBlackWhiteComments
AURA Pigment24KGsXXXXXUsed for all fabrics except acrylic.
Pre-treatment for digital  white ink25KGs     use 120 mesh screen

Resources

Brochure
